| Belt width (min/max), mm50 / 110 | Bushing diameter, mm12.7 (0.5" inch) | Roll winding length, mup to 100 |
| Thermal head resource50 km | Printer classDesktop | Print speedup to 101 mm/sec |
| Print typeThermal transfer | Print Resolution300 dpi | Flash memory256 Mb |
The MERTECH HT630 thermal transfer printer is designed for label printing. The model is suitable for any business sector that requires labeling. It can be used in wholesale and retail stores, in cafes and restaurants, in manufacturing, and in other areas of activity. The device quickly prints high-resolution labels with barcodes.
Advantages of the Model
The MERTECH HT630 desktop printer has high performance. During a working day, it can print up to 10,000 adhesive labels of 58x40 mm format. A set of automated sensors is used to monitor the working process. During printing, the device emits visual and audio signals.
The printing mechanism is equipped with a reliable thermal head. The need for replacement will not arise until after printing 50 kilometers of labels. The device can accommodate ribbons based on wax, resin, or a mixture of these two materials. The mechanism's design allows changing the ribbon or the cassette with adhesive labels in 15 seconds. The menu includes a fast ribbon rewind function.
The MERTECH HT630 thermal transfer printer can operate using TSPL, ZPL, and EPL protocols. It connects to a computer via Ethernet, RS232, or USB cable (optional — via Bluetooth). New fonts and templates from Bartender can be loaded into the device's memory. The available Flash memory capacity is 256 MB, and RAM is 128 MB.
The printer can print all popular 1D and 2D barcodes. It is suitable for printing PDF417, QR codes, and Data Matrix.
Technical Specifications
Specifications of the MERTECH HT630 model:
- Print speed: up to 152 mm/sec.
- Image resolution: 300 DPI.
- Ribbon width: from 50 to 110 mm.
- Print area width: from 25 to 106 mm.
- Print area length: from 15 to 1200 mm.
- Roll length: up to 100 m.
- Core diameter: 12.7 mm.
The model features a modern design with a user-friendly interface. The base of the housing is a rigid and stable metal frame. Polycarbonate and plastic panels are mounted on it. The durable outer panels can withstand significant impacts. With dimensions of 285x226x171 mm, the device weighs 2.045 kg.
You can order thermal transfer label printers on the MERTECH website. When contacting the manufacturer, the lowest prices for equipment apply. Delivery is possible to any region of Azerbaijan. Leave a request on the site to place an order.
Order thermal transfer label printers at a low price on the MERTECH website. Only by contacting the manufacturer directly can you access the lowest prices. Delivery of the equipment is carried out throughout Azerbaijan. Leave a request on the site to agree on the order conditions.
| Belt width (min/max), mm | 50 / 110 |
|---|---|
| Bushing diameter, mm | 12.7 (0.5" inch) |
| Roll winding length, m | up to 100 |
| Thermal head resource | 50 km |
| Printer class | Desktop |
| Print speed | up to 101 mm/sec |
| Print type | Thermal transfer |
| Print Resolution | 300 dpi |
| Flash memory | 256 Mb |
| RAM memory | 128 Mb |
| Printing protocol | TSPL, ZPL, EPL |
| Recommended print volume per day | 10,000 labels size 58x40 |
| Ribbon type | wax based, wax and resin, resin |
| Print area length, mm | 15 - 1200 |
| Ability to download fonts | Yes |
|---|---|
| Label Separator | Yes (optional) |
| Supported code pages | PC437, 720, 737, 755, 775, 850, 852, 855, 856, 857, 858, 860, 862, 863, 864, 865, 866; Windows1250, 1251, 1252, 1253, 1254, 1255, 1256, 1257, 1258; ISO8859-1, 2, 3, 4, 5, 6, 8, 9, 15; DBCS 932 (JIS), 936(GBK), 949 (Koran), 950(BIG5) |
| Tape rewind function | Yes |
| Поддержка СЭУАП | Yes |
| Cutter | Yes (optional, cutter resource 1 million) |
| Built-in sensors | Paper present, Lid open, Label gap, Print head temperature, Black marks, Ribbon end |
| External holder | Yes (optional) |
| OS support | Windows 7/ 8/ 10/ 11, Linux, MacOS |
| Sound and visual indication | Yes |
| Supported 1D barcodes | Code 39, Code 93, EAN 8/13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code, Planet 11 & 13 digit, Japanese Postnet, I 2 of 5 with human readable check digit, Standard 2 of 5, Industrial 2 of 5, Logmars, Code 11, Code 49, Cadablock |
| EasyLoad | Yes |
| Supported 2D barcodes | PDF417, Data matrix code, Maxi Code, QR code, Micro PDF417, Micro QR code, Aztec code |
| Print QR code | Yes |
| Bartender Support | Yes |
| Applications of the printer | For 1C, For OZON, For inventory, For shoe labeling, For warehouse, For labeling, For marketplace, For textile labels, For EVOTOR, For Wildberries |
|---|---|
| Storage temperature | -20°С ~ +50°С |
| Nutrition | DC 24V, 2.5A |
| Permissible humidity | 30 - 85% (operation); 10 - 90% (storage) |
| Operating temperature | 5 ~ 40°C |
| Network adapter cable length (m) | 3.1 |
| Roll core diameter | 1 inch (25.4 mm), 1.5 inch (38.1 mm), 3 inch (76.2 mm) |
|---|---|
| Paper width, mm | 25.4 -108 mm 25.4-106 mm |
| Paper thickness, mm | 0.06 - 0.250 (60 µm - 250 µm) |
| Roll diameter, mm | up to 127 |
| Printing material | Paper, textile and synthetic tapes, labels |
| Ribbon winding | OUT |
| Interfaces | USB + RS232, Ethernet, Wi-Fi - optional |
|---|
| Printer frame material | Metal |
|---|---|
| Color | Black |
| Overall dimensions (WxDxH), mm | 285*226*171 |
| Body material | ABC + PC (plastic + polycarbonate) |
| Weight | 2,045 kg |
| Equipment | Printer, USB interface connection cables, Power supply, Warranty card, Packaging |
|---|
| Print width, mm | from 25 mm to 106 mm |
|---|
-
