| Printer classDesktop | Print speed200 mm/sec | Print typeThermo |
| Print area width, mmUp to 72 | Print head resource150 km | Print Resolution203 dpi |
| Flash memory4 Mb | Printer typeReceipt printer | RAM memory2 Mb |
MERTECH F91 is a desktop printer designed for receipt printing. It operates on the principle of thermal printing. When the print head heats up and touches thermal paper, the medium changes color. The device can be connected to a cash register via a USB cable, RS-232 interfaces, or Ethernet.
Technical Specifications
The frame of the printer is made of metal. The casing is made from ABS plastic and polycarbonate PC. These are durable materials that protect the mechanism from impacts. The design can withstand falls from a height of 1.5 meters. Casing color: black. Protection level: IP 42.
Model specifications:
- Maximum speed: 200 mm/sec.
- Image resolution: up to 203 dpi.
- Medium material: thermal receipt paper.
- Width of thermal receipt paper: up to 80 mm.
- Print width: up to 72 mm.
- Thickness of receipt paper: 0.056 - 0.13 mm.
- Roll diameter: up to 83 mm.
- Protocol: ESC/POS.
The design includes a cutter for finished receipts. Cutter lifespan: 2 million operations. Thermal print head lifespan: 150 km. Printer memory: RAM 2 MB, Flash 4 MB. Operating temperature: from 0 to +45°C.
Advantages of the Model
The MERTECH F91 thermal printer is designed for printing receipts that comply with the "On Trade" law. It prints popular 1D barcodes as well as 2D barcodes PDF417 and QR Code. It supports ASCII and GBK fonts, Codepage 47. The device is adapted for use with automated systems.
Changing the receipt paper is done in 15 seconds using the EasyLoad system. The design includes cover open and paper presence sensors. If at least one sensor indicates an error, printing will not commence. Both auditory and visual indicators are provided for operation.
The printer's software synchronizes with Windows, Linux, POSReady, OPOS operating systems. The package includes a free program for managing receipt templates. USB and RS-232 cables are also included in the package.
How to Place an Order
You can purchase the MERTECH F91 thermal printer on the official MERTECH website. On the official site, the equipment is sold at low prices directly from the manufacturer. Delivery is available in Krasnodar and Krasnodar Krai. To buy receipt printers, leave a request on the website and wait for a call from the manager.
| Printer class | Desktop |
|---|---|
| Print speed | 200 mm/sec |
| Print type | Thermo |
| Print area width, mm | Up to 72 |
| Print head resource | 150 km |
| Print Resolution | 203 dpi |
| Flash memory | 4 Mb |
| Printer type | Receipt printer |
| RAM memory | 2 Mb |
| Printing protocol | ESC/POS |
| Поддержка СЭУАП | Yes |
|---|---|
| Cutter | Yes |
| Resource of the cutter | 2 million |
| Built-in sensors | Availability of paper; Opening of the lid |
| External holder | No |
| OS support | Windows XP/ Vista/ 7/ 8/ 8.1/ 10; Linux; OPOS; POSReady |
| Supported fonts | Chinese GBK 16x16, 24x24 dots; Alphanumeric ASCII 9x17, 12x24 dots; Encodings 47 |
| Sound and visual indication | Yes |
| Supported 1D barcodes | UPC-A; UPC-E; EAN-8; EAN-13; CODE 39; ITF; CODEBAR; CODE 128; CODE 93 |
| EasyLoad | Yes |
| Supported 2D barcodes | QR Code; PDF417 |
| Print QR code | Yes |
| Guarantee | 2 years |
|---|---|
| Resistance to external influences | IP42 |
| Storage temperature | -20°С ~ +60°С |
| Paper width, mm | up to 80 |
|---|---|
| Paper thickness, mm | 0.056 - 0.13 |
| Roll diameter, mm | up to 83 |
| Printing material | Receipt tape |
| Interfaces | USB; Ethernet; RJ12 |
|---|
| Printer frame material | Metal |
|---|---|
| Color | Black |
| Body material | ABC + PC (plastic + polycarbonate) |
| Equipment | Printer; Interface connection cables (RS232 and USB); Power supply; Warranty card; Packaging |
|---|
-
