| Type of scalesPacked, portioned | Discreteness0.1 gr | Minimum weight5 gr |
| Number of keys6 | Weighing limit6 kg | Platform size255x205 mm |
| ExecutionTabletop | VerificationYes | Accuracy classHigh (II) |
This product is currently being redesigned. The appearance of the product, including color, may differ slightly from what is shown in the photograph. Any discrepancies between the actual product's appearance and the photographs on the website do not indicate a defect in quality.
The M-ER 326 AFU-6.01 "Post II" LCD RS-232 model has improved metrological characteristics. This is a Class II accuracy weighing scale. It can be used as laboratory scales. The declared characteristics are confirmed by state verification. The model has a certificate confirming the accuracy class according to GOST.
Design Features
The small device will not take up much space on your desk. Dimensions of the body: 265*290*110 mm. Platform size: 255*205 mm. Weight of the device: 2.5 kg. The M-ER 326 AFU-6.01 "Post II" LCD RS-232 model is used as control scales in trade. It is applied in jewelry salons and workshops. It is used for scientific research purposes.
Several operating modes are available for users:
- Simple weighing;
- Comparator mode;
- Summation mode;
- Weighing result;
- Tare weight accounting;
The M-ER 326 AFU-6.01 "Post II" LCD RS-232 scales are available in several options. They differ in maximum weighing limits. On this page, the scales have a weighing range from 5 grams to 6 kilograms and a price division of 0.1 grams. The results of measurements and calculations are displayed on the LCD display.
Operating Rules
The M-ER 326 AFU-6.01 "Post II" LCD RS-232 RS232 LCD model has the following advantages:
- Simple and intuitive interface. Ergonomic control panel.
- Support for 3 units of measurement: grams, kilograms, pounds.
- The body is made of ABS plastic with increased strength.
- Large digit size on the LCD display (9*21 mm or 11*21 mm).
- Platform stabilization. Adjustable height of supports.
- RS-232 interface for connection to a POS computer.
Operation in heated and covered locations is permitted. Operating temperature range: from +10 to +40 degrees Celsius. The set includes only a protective dust cover. The device operates from the power supply. The power adapter is included in the kit.
Place an Order
You can purchase the M-ER 326 AFU-6.01 "Post II" LCD RS-232 RS232 LCD weighing scales at a low price directly from the manufacturer. Models from this line are always in stock. Orders are delivered throughout Baku or to any city in Azerbaijan. We guarantee fast and careful delivery of the product. Leave a request on the website or call us to make a purchase.
| Type of scales | Packed, portioned |
|---|---|
| Discreteness | 0.1 gr |
| Minimum weight | 5 gr |
| Number of keys | 6 |
| Weighing limit | 6 kg |
| Platform size | 255x205 mm |
| Execution | Tabletop |
| Verification | Yes |
| Accuracy class | High (II) |
| Load cells, pcs. | 1 |
| Operating modes | Simple weighing; Comparator mode; Summation mode; Weighing result; Tare weight accounting; Counting mode; Data transfer mode |
|---|---|
| Printing labels | No |
| Energy saving mode | Yes |
| Calibration | External |
| Tare sampling range | The whole range |
| Units of measurement | Gr; kg; ft; oz (optional) |
| Self-diagnosis mode | Yes |
| Visual indication | Yes |
| Level | Yes |
| Guarantee | 2 years |
|---|---|
| Applications of scales | For connection to 1C, For a store, For hardware, For connection to a POS computer, For food production, For meat, For confectionery, For bulk materials, For food products |
| Battery | 4V-4.5A |
| Verification | Yes |
| Nutrition | 5.8V - 0.5A |
| Permissible humidity | 80% at 40°C without condensation |
| Atmospheric pressure | 630...800 mm Hg (84...106.7 kPa) |
| Operating temperature | -10°C ~ +40°C |
| Display type | LCD |
|---|---|
| Number of displays | 1 |
| Number of indication digits | 6 |
| Character size, mm | 9x21 |
| CAS-M (Active) | Yes |
|---|---|
| CAS-M (Passive) | Yes |
| POS2-M | Yes |
| Interfaces | RS232 (DB-9F), length 2.7m |
|---|
| Weight with platform | 2.2 kg |
|---|---|
| Overall dimensions (WxDxH), mm | 265x290x110 |
| Platform material | Plastic |
| Body material | Plastic |
| Weight | 2.5 kg |
| Keyboard type | Membrane |
| Overload protection | No |
| Corrosion protection | Galvanization |
| Moisture protection | Dust film |
| Adjustable supports | Yes |
| Platform shape | Rectangular |
| Equipment | Power adapter, length 1.4m, Platform, Dust film, Warranty card, Operation manual |
|---|
-
