| Scanner typeEmbedded | Scanning element2D image | Scanning speed100 scans/sec |
| Connection typeWired | Scanner resolution640(H)x480(V)Px | Scanning coverage angle50º(h)x35º(v) |
| Barcode SensitivityTilt ± 65° / 360° Rotation / Deviation ± 60 ° | Minimum barcode contrast20% | Reading barcodes1D, 2D |
The MERTECH T8900 is an embedded barcode scanner. It is designed to read 2D and 1D codes. The device can be integrated into a work area or mounted on a table. A wired connection is used to connect to the database.
Technical specifications
The body of the model is made of plastic and polycarbonate (ABC + PC). The body shape is rectangular, the color of the panels is black. Dimensions: 143*119*67 mm. The device weighs 209 grams. Protection against falling from a level of 150 cm is provided. Enclosure protection level against dust and humidity: IP54.
Main features of the scanner:
- Speed: up to 100 scans per second.
- Scanning distance: up to 200 mm.
- Coverage angle: 50*35 degrees.
- Resolution: from 4.0 MIL.
- The minimum barcode contrast is 20%.
- Temperature range for operation: from 0C to +50C.
A USB-HID interface is used to connect to an online sales register, POS terminal, or computer. Additionally, you can order USB-COM and RS-232 emulation.
The operation of the device is accompanied by an audible and visual indication. Scanning takes place automatically when the label enters the range of the scanning module.
Advantages of the model
The MERTECH T8900 barcode scanner is designed specifically to work in the Honest SIGN system and alcohol accounting according to the Unified State Register of Medical Sciences. It recognizes all known barcodes, including the DataMatrix code, which is used for labeling products. The labels are scanned using SUPERLEAD technology.
The reader uses 2D Image technology. It photographs labels and recognizes codes using the built-in program. This model has a 617K red LED backlight. Thanks to the backlight, clearer photos are obtained, and recognition is faster.
The device recognizes damaged and indistinct labels. Easily reads small barcodes from cigarette packages. The glare film is not an obstacle to scanning. The reader recognizes data from screens and other complex surfaces.
How to make a purchase
You can purchase an embedded barcode scanner in our online store. Delivery of equipment is carried out in Moscow and all regions of Russia. To make a purchase, leave a request on the website or call by phone.
| Scanner type | Embedded |
|---|---|
| Scanning element | 2D image |
| Scanning speed | 100 scans/sec |
| Connection type | Wired |
| Scanner resolution | 640(H)x480(V)Px |
| Scanning coverage angle | 50º(h)x35º(v) |
| Barcode Sensitivity | Tilt ± 65° / 360° Rotation / Deviation ± 60 ° |
| Minimum barcode contrast | 20% |
| Reading barcodes | 1D, 2D |
| Scanning range | Up to 200 mm |
| Поддержка СЭУАП | Yes |
|---|---|
| Sound and visual indication | Yes |
| Supported 1D barcodes | UPC; EAN; Code128; Code 39; Code 93; Code11; Matrix 2 of 5; Interleaved 2 of 5; Codabar;MSI Plessey; GS1 DataBar; China Postal; Korean Postal |
| Supported 2D barcodes | PDF417; MicroPDF417; Data Matrix; Maxicode; QR Code; MicroQR; Aztec; Hanxin |
| EGAIS support | Yes |
| Automatic scanning | Yes |
| Recognizing barcodes from complex surfaces | Yes |
| Support Honest SIGN | Yes |
| Backlight | Red 617K LED |
|---|
| 5 MIL | 0-60 mm |
|---|---|
| 13 MIL | 0-150 mm |
| Minimum scanning resolution | 4 MIL |
| Guarantee | 3 years old |
|---|---|
| Resistance to external influences | IP54 |
| Storage temperature | -40°C ~ +70°C |
| Permissible humidity | 0% ~ 95% |
| Operating temperature | 0°C ~ +50°C |
| Drop test | It can withstand multiple falls from a height of 1.5 m. |
| Interface | USB-HID; USB-COM emulation; RS232 - optional |
|---|
| Color | Black |
|---|---|
| Overall dimensions (WxDxH), mm | 143*119*67 |
| Body material | ABC + PC (plastic + polycarbonate) |
| Weight | 209 grams |
| Quantity in masterbox, pcs | 50 pcs |
|---|---|
| Equipment | Scanner, USB type A cable, Instructions, Warranty card, Packaging |
-
