Built-in barcode scanner MERTECH N120 P2D

Built-in barcode scanner MERTECH N120 P2D 153 ₼

In stock Product code: 4100

153 ₼

Quick order

Specification

Scanner typeBuilt-in	Scanning element2D image	Scanning speed100 scans/sec
Connection typeWired	Scanner resolution752(h)х480(v)Px	Scanning coverage angle115º(h)x90º(v)
Barcode SensitivityTilt ±65° / Rotate 360° / Roll ±60°	Minimum barcode contrast20%	Reading barcodes1D, 2D

All Attributes

Shipping Information

Description

MERTECH N120 P2D is an embedded two-dimensional scanner from MERTECH. It recognizes all known 1D and 2D barcodes. Thanks to the patented SuperLead technology, scanning occurs instantly. This compact scanner is suitable for installation in vending machines. It can also be used as a mobile barcode reader.

Technical Specifications

The device measures 67*67*35 mm. The small unit weighs only 100 g. The model's case is made of primary plastic and polycarbonate (ABC+PC). The reinforced design withstands mechanical shocks and falls from a height of up to 1.5 m. The degree of protection against dust and moisture is IP54.

Here are the main features of the model:

Scanning speed: 100 scans per second.
Scanning distance: 110 mm.
Minimum barcode contrast: 20%.
Field of view: 65*360*60 degrees.
Built-in illumination: 6500K white LED.
Screen resolution: 640*480 pixels.
Power supply: 3.3-5V/300mA.

The MERTECH N120 P2D scanner connects via a wired connection. It can be connected to the system using USB-HID, USB-COM (emulation), RS232 (optional) interfaces. The package includes a USB cable with a length of 1.8 m.

Advantages of the Model

The embedded MERTECH N120 P2D scanner recognizes barcodes in challenging conditions. It can read data even from reflective surfaces and mobile device screens. Thanks to the built-in illumination, the device recognizes damaged and poorly printed codes.

The device automatically wakes up from sleep mode when an item with a barcode is brought near it. The automatic mode speeds up customer service. The scanning procedure is accompanied by sound and visual indicators.

The scanner connects to online cash registers such as Merkuriy, Evotor, Shtrikh, ATOL, and other brands. Drivers for synchronization are included in the package. The model is suitable for working with the labeling of alcoholic and tobacco products, footwear, clothing, pharmaceuticals, and other goods.

Place an Order

You can purchase the MERTECH N120 P2D embedded scanner at a factory price. We sell the equipment without a markup. Delivery of the equipment is carried out through an extensive dealer network. You can order the delivery of the equipment to any city in Azerbaijan. Place an order in the online store or leave a request on the website to make a purchase.

Specifications Built-in barcode scanner MERTECH N120 P2D

Technical parameters

Scanner type	Built-in
Scanning element	2D image
Scanning speed	100 scans/sec
Connection type	Wired
Scanner resolution	752(h)х480(v)Px
Scanning coverage angle	115º(h)x90º(v)
Barcode Sensitivity	Tilt ±65° / Rotate 360° / Roll ±60°
Minimum barcode contrast	20%
Reading barcodes	1D, 2D
Scanning range	Up to 370 mm

Functional capabilities

Поддержка СЭУАП	Yes
Sound and visual indication	Yes
Supported 1D barcodes	UPC; EAN; Code128; Code 39; Code 93; Code11; Matrix 2 of 5; Interleaved 2 of 5; Codabar;MSI Plessey; GS1 DataBar; China Postal; Korean Postal
Supported 2D barcodes	PDF417; MicroPDF417; Data Matrix; Maxicode; QR Code; MicroQR; Aztec; Hanxin
Automatic scanning	Yes
Recognizing barcodes from complex surfaces	Yes
Support Honest SIGN	Yes

Scanner specifications

Backlight	White 6500K LED

Scanning range

5 MIL	0-20 mm
13 MIL	0-50 mm
Minimum scanning resolution	5 MIL

Operating parameters

Guarantee	3 years
Resistance to external influences	IP54
Storage temperature	-40°С ~ +70°С
Permissible humidity	0% ~ 95%
Operating temperature	-0°С ~ +50°С
Drop test	Withstands multiple drops from a height of 1.5 m
