Benchtop scales M-ER 222 F-32.5 "Connect" LCD USB (COM)

M-ER 222 F-32.5 "Connect" LCD USB (COM) is an ultra-thin bench scale. The model can be used for integration into checkout counters or boxes. The built-in model saves space on the cashier's working desk. A USB (COM) interface is used to connect to the POS system. The weighing results are displayed on an LCD screen (with backlight).

Design Features

The M-ER 222 F model is distinguished by its compact dimensions. The body dimensions are 330*320*80 mm. The platform size is 330*255 mm. These are among the thinnest scales available on the market. The accuracy class of weighing is III. The device operates on the CAS-M protocol.

MERTECH offers 2 variants of the model. They differ in weighing limits:

1. M-ER 222 F-15.2. Maximum load – 15 kg. Minimum load – 40 grams. Division price – 2 grams.
2. M-ER 222 F-32.5. Maximum load – 32 kg. Minimum load – 100 grams. Division price – 5 grams.

Included in the package is a remote LCD display. The user can turn the screen backlight on and off. The equipment operates from the power grid. An adapter for power supply is included in the package.

Operating Rules

The device can be installed on a flat surface that is not subject to vibration. The platform should be positioned horizontally. Its position can be adjusted using supports. After installation, it should be connected to the POS computer via a USB (COM) cable. Synchronization with most online cash registers happens automatically (drivers are included in the package).

After installation, the device can be turned on. The display will count down to 0. After that, a "0" will appear on the screen, and the stabilization indicator will turn on. When this happens, the equipment will be ready for operation. Weighing of goods can then begin. The results will be displayed on the screen and transmitted to the POS system.

Overloading the scales by more than 5 times the maximum weighing limit is not allowed.

Place an Order

You can buy the M-ER 222AF "Connect" trading scales at a low price. We sell the equipment without a markup, directly from the manufacturer. Delivery of goods is available in Baku or throughout Azerbaijan. Free consultations on integration, connection, and configuration of the scales are available. To place an order, call the phone number or leave a request on the website.
