| Type of scalesPackaging | Discreteness5 gr | Minimum weight100 gr |
| Weighing limit32 kg | Platform size330*255 mm | ExecutionTabletop |
| VerificationYes | Accuracy classAverage (III) | Load cells, pcs.1 |
M-ER 222 F-32.5 "Connect" LCD RS-232 is an ultra-thin scale for weighing. This model can be used for integration into cash registers or boxes. The built-in model saves space on the cashier's desk. The RS-232 interface is used for connecting to the POS system. Weighing results are displayed on an LCD screen (with backlight).
Design Features
The M-ER 222 F model is distinguished by its compact dimensions. Body dimensions: 330*320*80 mm. Platform size: 330*255 mm. These are among the thinnest scales available on the market. The weighing accuracy class is III. The device operates on the CAS-M protocol.
MERTECH offers 2 variants of this model. They differ in their weighing limits:
- M-ER 222 F-15.2. Maximum load – 15 kg. Minimum load – 40 grams. Division price – 2 grams.
- M-ER 222 F-32.5. Maximum load – 32 kg. Minimum load – 100 grams. Division price – 5 grams.
The package includes a remote LCD display. The user can turn the screen backlight on and off. The equipment operates from the mains. A power adapter is included in the package.
Operating Instructions
The device can be installed on a flat surface that is free from vibration. The platform must be positioned horizontally. Its position can be adjusted using supports. After installation, it should be connected to the POS computer via the RS-232 cable. Synchronization with most online cash registers occurs automatically (drivers are included in the package).
Once installed, the device can be turned on. The display will count down to 0. After this, "0" will appear on the screen and the stabilization indicator will light up. When this happens, the device will be ready for operation. You can start weighing products. The results will be displayed on the screen and transmitted to the POS system.
Overloading the scales by more than 5 times the maximum weighing limit is not permitted.
Placing an Order
You can buy the M-ER 222AF "Connect" trading scales at a low price. We sell the equipment without a trade markup, directly from the manufacturer. Delivery of goods is available in Baku or throughout Azerbaijan. Free consultations on installation, connection, and setup of the scales are available. To place an order, call the phone number or leave a request on the website.
| Type of scales | Packaging |
|---|---|
| Discreteness | 5 gr |
| Minimum weight | 100 gr |
| Weighing limit | 32 kg |
| Platform size | 330*255 mm |
| Execution | Tabletop |
| Verification | Yes |
| Accuracy class | Average (III) |
| Load cells, pcs. | 1 |
| Tare sampling range | The whole range |
|---|---|
| Units of measurement | Gr; kg |
| Self-diagnosis mode | Yes |
| Visual indication | Yes |
| Level | Yes |
| Guarantee | 2 years |
|---|---|
| Applications of scales | For connection to 1C, For a store, For connection to a POS computer, For food products |
| Verification | Yes |
| Nutrition | via USB |
| Permissible humidity | 85% |
| Atmospheric pressure | 630...800 mm Hg |
| Operating temperature | -10°C ~ +40°C |
| Display type | LCD |
|---|---|
| Number of indication digits | 5 |
| Character size, mm | 8*21 |
| Interfaces | RS-232 |
|---|
| Overall dimensions (WxDxH), mm | 340*240*77 |
|---|---|
| Platform material | Stainless steel |
| Body material | Plastic, metal |
| Weight | 3.75 kg |
| Keyboard type | Industrial sensor |
| Overload protection | Sound and visual notification |
| Corrosion protection | Galvanization |
| Moisture protection | IP 54 |
| Adjustable supports | Yes |
-
